Earthing Cables

Conductors: It is the current carrying component of the cable.
Material: Stranded, high conductivity plain annealed copper wires as per class 2 in BS 60228 and IEC 60228. Aluminium, stranded, compacted conductors

Insulation: The rated voltage level depends on the dielectric strength and thickness of insulation.
Material: he insulation of standard wiring cables is PVC grade Type T1 of BS 7655 (formerly BS 6746) suitable for a Maximum continuous conductor operating temperature of 70°C.

<span class="ts-tooltip button-tooltip">Compare</span>

Description

Technical Characteristics
  • Voltage Rating: 450/750 Volts
  • Temperature Rating: -5°C to +70°C
  • Minimum Bending Radius: Fixed: 6 × overall diameter
Core Identification

1 Core: Red, Black, Yellow, Blue, Green/Yellow (Other colors as per specification can also be manufactured).

Applicable Standards
  • BS EN 50525-2-31: For PVC Insulated Wiring
  • BS EN 60228: For Conductor
  • BS 7655: For Insulation
  • BS EN/IEC 60332-1: For Flame Retardant
Application

Domestic wiring cable. Can be installed in fixed installations in dry or damp premises clipped to surface, on trays or in free air where the risk of mechanical damage would not be an issue. Suitable for laying in conduit or trunking where mechanical protection is required.
